HPS Distributor
The electrification of the mobility sector requires, among other things, an efficient connection of current-carrying lines in high-voltage vehicle electrical systems. For example, it becomes increasingly necessary to distribute power to two HV units. With our HPS Distributors, this can be achieved safely.
The product design of our power distributors impresses with its extremely compact construction and its high scalability – due the use of standard components, we can cover a wide range of cross-sections.
Technical Sales
- compliant with automotive test specification LV 214
- watertight according to IP6K9K
- 360° shielded connection
- different cable cross section possible
- compact design
- high current load at high ambient temperatures
| PARAMETERS | Y/H Distributor |
| Current Class | current class 1 and 2 connector |
| Applications | power distribution |
| Operating Condition | U = 1,000 VDC |
| Voltage Class | Class B according to ISO 6469-3:2011 60 VDC < U ≤ 1,000 VDC 25 VAC < Ueff ≤ 707 VAC (15-150 Hz) |
| Ambient Condition | -40° C to +140° C |
| Maximum Altitude | 4,000 m |
| Maximum Current Load | 88A at 80° C (6.00 mm2), see deratings product specification |
| IP-Degree of Protection | IPXXD (assembled) |
| Watertightness | IP6K9K, IPX8 |
| EMC Performance (6.00 mm2) | until 30 MHz < 1 mΩ/m > 75 dB (10 kHz to 500 MHz) > 65 dB (500 MHz to 1,000 MHz) |
| Shielded Area | 360° circumferential |
| Shield Contact Resistance | < 2,0mΩ (total from sheathed cable until aggregate housing) |
| Vibration Strength 2 | according to LV214/215 - PG17 (without fixation point) |
| Vibration Strength 3 | according to LV214/215 - PG17 (first fixation point at < 200 mm) |
| Vibration Strength 4 | according to LV214/215 - PG17 (first fixation point at < 50 mm) |
| CONNECTION INFORMATION | |
| Connection | ultrasonic welding |
| CUSTOMER-SPECIFIC INFORMATION | |
| Cable Cross Section | 2.5 mm2; 4.0 mm2; 6.0 mm2 as MCC and SCC solutions |
